Technical Data
5.2 Technical data for D445
parameters Values
Without mounting and fan/battery module With
mounting and fan/battery module
(max. expansion)
50x380x230
50x380x270
Weight of SIMOTION D [g] Approximately 2500
Weight of SIMOTION CF [g] 7
Ambient conditions
Table 5-4 Environmental requirements
parameters Values
Permissible ambient temperature
Storage and transport
Operation
-40°C... +70°C
0°C... +55°C
Permissible relative humidity
(without condensation)
5% ... 95%
Air pressure 700 hPa...1060 hPa
Degree of protection according to IEC 529 IP20
5.2 Technical data for D445
Technical Data
The following technical data are relevant for the D445.
Additional references
For information on system clocks and address ranges of the SIMOTION D445, refer to the
SIMOTION SCOUT configuration manual.
Memory for user data
Table 5-5 Memories for user data and their memory size
Data Memory size
Diagnostics buffer 100 messages
D4xx
5-2 Manual, 12.2004, 6AU1900-1AJ32-0BA0
