Spare parts/accessories
7.5 Terminal module TM41
Interface Number
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
Additional references
You can find additional information about the TM31 in the SINAMICS S120 product manual
and the SINAMICS S120 commissioning manual.
Caution
The 50 mm clearances above and below the components must be observed.
7.5 Terminal module TM41
Features of the TM41
With the terminal module TM41, the number of available digital inputs and outputs and the
number of analog outputs within a drive can be expanded. In addition, one channel can be
used for encoder simulation. The TM41 can be connected by means of DRIVE CLiQ.
The TB41 contains the following terminals:
Table 7-3 TM41 interface overview
Type Number
Digital inputs 4
Digital inputs/outputs 4
Analog inputs 1
TTL encoder output 1
Additional references
For further information on the TM41 terminal module please see Equipment Manual TM41.
Caution
The 50 mm clearances above and below the components must be observed.
D4xx
7-6 Manual, 12.2004, 6AU1900-1AJ32-0BA0
