Siemens SINAMICS DCM User Manual

Functional safety
13.9 Circuit breakers and power contactors
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
727
6RA8096_XXXXX_0AA0
Value Designation Manu-
facturer
Article number
Rated DC current [A] (DC)
2200
-
-
-
Rated armature supply
voltage [V]
575
690
950
- - -
3WL circuit breaker
armature circuit
- 3WL1 circuit breaker 2000 A 690 V with
LI trigger ETU15B
3WL1 circuit breaker 2000 A 1000 V with
LI trigger ETU15B
Siemens
Siemens
3WL1220-3BB33-4AS2-Z
Z=C22
3WL1220-4BB33-4AS2-Z
Z=A05+C22
Contactor field circuit - Field contactor designed for AC1
Field contactor designed for AC1
Siemens
Siemens
3RT1034-3AL20
3RT1044-3AL20
6RA8097_XXXXX_0AA0
Value Designation Manu-
facturer
Article number
Rated DC current [A] (DC) 2600
2800
- - -
Rated armature supply
voltage [V]
575
690
- - -
3WL circuit breaker
armature circuit
- 3WL1 circuit breaker 2500 A 690 V with
LI trigger ETU15B
Siemens 3WL1225-3BB33-4AS2-Z
Z=C22
Contactor field circuit - Field contactor designed for AC1
Field contactor designed for AC1
Siemens
Siemens
3RT1034-3AL20
3RT1044-3AL20
6RA8098_XXXXX_0AA0
Value Designation Manu-
facturer
Article number
Rated DC current [A] (DC)
3000
-
-
-
Rated armature supply
voltage [V]
400 - - -
3WL circuit breaker
armature circuit
- 3WL1 circuit breaker 2500 A 690 V with
LI trigger ETU15B
Siemens 3WL1225-3BB33-4AS2-Z
Z=C22
Contactor field circuit - Field contactor designed for AC1
Field contactor designed for AC1
Siemens
Siemens
3RT1034-3AL20
3RT1044-3AL20
