Siemens SINAMICS PERFECT HARMONY GH150 User Manual

LED Color Status Description; cause Remedy
RUN /
ERR
- Off The electronic power supply is missing or
lies outside the permissible tolerance
range.
-
Green Continuous
light
The component is ready for operation
and cyclic DRIVE-CLiQ communication
is in progress.
-
Orange Continuous
light
DRIVE-CLiQ communication is being es‐
tablished.
-
Red Continuous
light
At least one fault is present in the com‐
ponent.
LED is controlled irrespective of the cor‐
responding messages being reconfig‐
ured.
Remedy and acknowledge fault.
Green/red 0.5 Hz flashing
light
Firmware download in progress. -
2 Hz flashing
light
Firmware download is complete. Waiting
for POWER ON.
Carry out a POWER ON.
Green/
orange
or
Red/orange
Flashing light Component recognition via LED is acti‐
vated.
The color depends on the LED state
when component recognition is activated.
-
8.4.2.2 LEDs of the Sirius safety relay
Table 8-2 LEDs of the Sirius safety relay
LED Operation
POWER CHANNEL1 CHANNEL2 Line supply EMERGENCY
STOP
ON Release circuits
☀ ☀ ☀ On Not actuated Actuated Closed
☀ ○ ○ Actuated Not actuated Open
☀ ○ ○ Not actuated Not actuated Open
Fault
☀ ○ ○
● Relay jammed
● Motor contactor jammed
● Defect in electronics
Open
○ ○ ○ Cross-circuit/ground fault in EMERGENCY STOP
circuit/no supply voltage
Operation
8.4 Fault and system messages
SINAMICS PERFECT HARMONY GH150 6SL38253AE412AA1-Z
Operating Instructions Rev.201910281231 EXAMPLE 101
