3. Pay attention to the center of gravity imprinted on the box ② and the imprinted position of
the ropes ③.
4. Carefully raise the transportation unit.
① Spreader beam
② Center of gravity
③ Imprinted position of the rope
Figure 4-5 Transporting a transportation unit (still in packaging) with a crane
See also
Transport with a fork-lift truck (Page 62)
Transport with a crane (Page 63)
4.3.8 Transporting a re-cooling unit
NOTICE
Damage to the ion exchange cartridge as a result of frost
If the ion exchange cartridge is exposed to frost, it may be damaged.
● Only transport and store the ion exchange cartridge in non-frosty conditions. More
information is available in the re-cooling unit's operating instructions.
Preparations for use
4.3 Transport
SINAMICS PERFECT HARMONY GH150 6SL38253AE412AA1-Z
66 Operating Instructions Rev.201910281231 EXAMPLE
