Technical data and drawings
B
B.1 Standards and regulations
Standards and regulations
Table B-1 Standards and regulations
Standards and regulations
Standards DIN EN 61800-5-1/VDE 0160 T105 (IEC 61800-5-1)
DIN EN 61800-3/VDE 0160 T103 (IEC 61800-3)
DIN EN 61800-4/VDE 0160 T104 (IEC 61800-4), however, only when refer‐
enced in the standards DIN EN 61800-3 or DIN EN 61800-5-1
DIN EN 60204-11/VDE 0113 T11 (IEC 60204-11)
EU Directives 2014/35/EU + amendments (Low Voltage Directive)
2014/30/EU + amendments (Electromagnetic Compatibility)
Insulation According to DIN EN 50178/VDE 0160 (IEC 62103), IEC 61800-5-1:
Pollution degree 2 (without conductive pollution), non-condensing
Protection class Class 1 according to DIN EN 61800-5-1/VDE 0160 T105 (IEC 61800-5-1)
Touch protection DIN EN 50274/VDE 0660 T514 and BGV A3 when used for the intended
application
Emitted interference This drive unit is part of a PDS, Category C4 according to DIN EN 61800-3/
VDE 0160 T103 (IEC 61800-3). The drive unit has not been designed to be
connected to the public line supply. The equipment can cause electromag‐
netic interference when it is connected to the public network. The essential
requirements placed on EMC protection for the drive system should be se‐
cured using an EMC plan at the customer site.
B.2 Environmental conditions
Climatic environmental conditions
Table B-2 Climatic environmental conditions
Storage with suitable packag‐
ing
Transport with suitable pack‐
aging
Operation (industrial)
Ambient temperature -25° C to +70° C -25° C to +70° C 5° C to +40° C
Relative humidity 5% to 95%
(Only low condensation is
permitted. The device must
be completely dry before
commissioning.)
5% to 75% 5% to 85%
(Condensation is not permit‐
ted)
SINAMICS PERFECT HARMONY GH150 6SL38253AE412AA1-Z
Operating Instructions Rev.201910281231 EXAMPLE 147
