ATYSt - 541995C - SOCOMEC
5.5. ATySt ACCESSORIES AVAILABLE
BRIDGING BARS
To connect switch I & II load terminals together.
TERMINAL SHROUDS (125 TO 630 A)
Incoming and outgoing protection against direct
contact with the connection terminals or parts. Cannot
be mounted in the rear position at the same time as
the voltage sensing and power outlet kit or the bridging
bars.
Can be mounted top or bottom, in front or in rear
position.
TERMINAL SCREENS
Incoming and outgoing protection against direct
contact with the connection terminals or parts.
DOOR ESCUTCHEON PLATE
An accessory to be xed onto a cabinet door to frame
the controller part of ush mounted ATySp transfer
switches.
DC POWER SUPPLY (DC -> AC)
Allows a standard 230Vac ATySt to be supplied
through a 12/24/48Vdc Aux Power supply.
SUPPLEMENTARY AUXILIARY CONTACT (AC)
Pre-breaking and signaling of positions I and II: 1
additional auxiliary contact NO / NC auxiliary contact
in each position. Included as standard for ratings from
2000 to 3200A. For Low level AC: please consult
SOCOMEC.
KEY LOCK AUTO / MANUAL SELECTOR SWITCH
The ATySt mode selector switch is delivered with a
rotary handle as standard. This can be replaced with a
key lock.
RONIS KEY PADLOCKING ACCESSORIES
Locking of the electrical and manual operation by
means of a RONIS EL11AP lock. Possibility of locking
in all positions, if the “Padlocking in the 3 positions”
option is ordered.
Not compatible with ush mounting.
PADLOCKING IN 3 POSITIONS
Allows locking of the operation in the 3 positions I, 0
and II. (Factory tted accessory)
CONTROL VOLTAGE TRANSFORMER
Allows a standard 230 V AC device to be supplied with
400VAC.
REMOTE INTERFACES D10
Remote Display: Allows source supply state and switch
positions to be displayed remotely. (LED display)
Typically door mounted or ≤3m away from the ATyS.
COMMUNICATION CABLE
RJ 45 communication cable (3m long) for use with the
D10 remote display/controller or Ethernet modules.
Others:
Refer to the end of this instruction manual or the latest
SOCOMEC product catalogue.
(Downloadable from www.socomec.com)
