socomec ATyS t User Manual

29
EN
ATYSt - 541995C - SOCOMEC
6.1.3. Dimensions: Frame B8 (2000 A to 3200 A)
3
56
3
1
= =
4
3
2
5
7
J
mm
Fix. M
867,5
12012,5 53,5 120 120
F
fix. 250
288 380 461
133,5
320
386
425
524
48
250
265
149
90
51,5
169166
280
44
200
138
165
9
12.5
5 5
15
90
30 30
45 45
25 25
2000 A - 3200 A
ø 12,5
1. Padlocking Facility: Locking bracket for up to 3 padlocks of dia. 4 – 8mm
2. Emergency manual operation: Maximum operating radius with an operating angle of 2x 90°
3. Connection and disconnection area
4. Terminal screens
5. Phase Barriers
6. Emergency removable handle
7. Flush mounting cutout dimensions for front door
2000 A 3200 A
3P 4P 3P 4P
F
596 716 596 716
J
398,5 518,5 398,5 518,5
M
347 467 347 467
CAUTION
To consider the space required for manual operation and wiring (when using the ATySg
emergency handle: note 2).
