socomec ATyS t User Manual

33
EN
ATYSt - 541995C - SOCOMEC
6.3.5. Copper bar connection kits (2000 A to 3200 A : Frame B8)
Dual dimensions in/mm
0.98
25
0.98
25
1.18
30
1.18
30
3.54
90
0.59
15
0.49 12,5
Ø 0.49
Ø 12,5
17.18
436,5
14.96
380
13.6 / 347 (3P)
18.38 / 467 (4P)
18.81 / 478 (3P)
23.54 / 598 (4P)
4.72
120
9.84
250
10.15
258
4.72
120
4.72
120
2.10
53,5
2.02
51,5
6.41
163
8.89
226
1.18 (4x)
30 (4x)
Conditions of use of these products
may lead to a derating.
!
SOCOMEC “Application guide”
www.socomec.com
3 P 4 P
3 P
4 P
3 P 4 P
provided
fourni
I th = 2000 A1
I th = 2500 A
2
I th = 3200 A
3
9.92
252
2.91
74
1.45
37
2.91
74
2.36
60
1.45
37
5.07
129
6.10
155
VERSION 04
VERSION 01
5.19
132
8.30
211
0.86
22
1.18 (4x)
30 (4x)
1.18 (4x)
30 (4x)
VERSION 02 - 03 - 05 - 06 - 09 - 12
VERSION 07 - 08 - 10 - 11
708 lb-in
80 Nm
VERSION
Rondelle contact
MOY. M M12
NFE 25 511
H M12
01 H M12-35 6.8 - 6 x 12 x 6 x
02 H M12-55 6.8 - 3 x 6 x 3 x
03 H M12-55 6.8 - 5 x 10 x 5 x
04
H M12-35 6.8 - 3 x 3 x -
H M12-45 6.8 - 3 x 3 x -
05 H M12-65 6.8 - 3 x 6 x 3 x
06 H M12-65 6.8 - 5 x 10 x 5 x
07 H M12-55 6.8 - 3 x 6 x 3 x
08 H M12-55 6.8 - 5 x 10 x 5 x
09 H M12-55 6.8 - 10 x 20 x 10 x
10 H M12-65 6.8 - 3 x 6 x 3 x
11 H M12-65 6.8 - 5 x 10 x 5 x
12 H M12-65 6.8 - 10 x 20 x 10 x
A
B
Connection reference numbers and contents:
x 1
included with 3200A
product as standard
2619 1200
708 lb-in
80 Nm
x 6
2699 1200
2699 1201
+
708 lb-in
80 Nm
x 1
x 6
2629 1200
+
708 lb-in
80 Nm
x 2
x 6
2639 1200
+
708 lb-in
80 Nm
x 1
x 6
4109 0250
+
708 lb-in
80 Nm
x 1
x 6
4109 0320
Data for Bolts, Nuls and Washers for Busbar Connections.
TO BE SUPPLIED BY OTHERS
!
Note: Reference numbers and quantity given above and below are for one connection and per pole.
For a full set multiply the quantity indicated by the number of poles (3 or 4 pole) and then multiply by 2 (N° of switches)
