12. TROUBLE SHOOTING GUIDE
The ATySt does not
operate electrically
• Verify the power supply on terminals 101-102 and 201-202: 208 - 277 Vac ±20 %
• Verify that the front selector switch is in position (AUT)
• Verify that contacts 313 and 317 are open.
• Verify that the power LED (Green) is On whilst the fault LED (RED) is off.
• Verify that the Ready light on the ATS controller is a steady Green light.
• Verify presence of at least one green LED on the source supply available LED’s .
• Verify that the product is available with contacts 63A / 64A and 63B / 64B closed.
• Verify whether the problem is limited to the ATS controls + the motorisation module or
just the ATS controls.
Note: To isolate the fault to the ATS controller or the complete unit, close contacts 312
with 317 whilst ensuring that 313 and 317 remain open. This will force the ATySt into
remote control which will bypass the ATS controller and accept position orders from
contacts 314 to 317.
It is not possible to
manually operate the
switch
• Verify that the front selector switch position is on the Manual position.
• Make sure that the product is not padlocked
• Verify the rotation direction of the handle
• Apply a sufcient progressive action in the direction as indicated on the handle
Electrical operation
does not correspond
to external order I,O,II
• Verify the selected control logic wiring (impulse or contactor)
• Verify the connector connections.
Impossible to
padlock
• Verify that the front selector switch is in manual position
• Verify that the emergency handle for manual operation is not inserted into the ATyS
manual slot.
• Verify that the ATyS is in 0 position
• (Padlocking is only possible in 0 position for standard products)
The ready light
remains ashing
• The Ready light ashes so as to indicate that the saved conguration is not identical
to what is displayed on the ATS controller. This could be due to a user not yet having
saved the conguration settings or that the potentiometer setting was changed and
has not been saved. To get a steady READY light either revert to the settings in the
ATySt or save the new settings. To save put into manual mode and press the PROG
OK button momentarily.
The AUT light is
ashing
• The AUT LED will be steady green when in AUTO Mode and will be ashing green
when the ATySt has timers running.
• This is usually a normal indication.
The fault LED is ON
(Motorisation)
• The FAULT / MANUAL LED on the motorisation module is on when in manual mode
(this is normal) and in AUT Mode when there is an internal fault in the ATySt. To reset a
fault condition switch the ATySt from AUT to Manu and back to AUT. Should the fault
LED remain on you will need to localize and clear the fault prior to reset.
• The FAULT / Manual LED will also be on when contact 313 is closed with 317. (Force
the ATyS to off position). This is a normal condition.
• The FAULT LED will also illuminate when the aux power supply is present but out of
range.
• Should the Fault LED remain on abnormally, contact SOCOMEC.
The fault LED is on
(ATS Controller)
• Switch the ATySt from AUT to Manual and back to AUT. Should the fault condition
remain contact SOCOMEC)
Sources availability
LEDs and fault LED
are blinking
• Check phase rotation consistency between both sources.
• Check neutral position consistency between both sources.
