Sony HCD-PZ1D - MAIN Board

HCD-PZ1D
23
2-23. MAIN BOARD
1 Lift up two lead pins.
1 Lift up two lead pins.
1 Lift up two
lead pins.
5 two screws
(BVTP 3 u8)
6 two claws
9
7 connector
(CN403)
8 connector
(CN405)
qg connector
(CN951)
MAIN board
AMP board
AMP board
MAIN board
WIRE HOLDER A board
:LUHVHWWLQJ
:LUHVHWWLQJ
–5HDUYLHZ–
2 flexible flat cable
(21 core)
(CN501)
0 flexible flat cable
(5 core)
(CN101)
qh wire (flat type)
(5 core)
(CN511)
qs wire (flat type)
(7 core)
(CN191)
qa flexible flat cable
(9 core)
(CN211)
qd flexible flat cable
(9 core)
(CN504)
qf wire (flat type)
(13 core)
(CN641)
3 connector (CN002)
4 wire (flat type) (7 core)
(CN503)
qj pet sheet
qk MAIN board
front side
front side
front side
front side
Insert is straight
to the interior.
connector
Insert is incline
flexible
cable
connector
flexible
cable
OK NG
Note:
When you install the flat cable, please
install them correctly.
There is a possibility that this machine
damages when not correctly installing it.
lead pin
lead pin
lead pin
lead pin
lead pin
lead pin
lead pin
