HCD-PZ1D
25
2-25. VIDEO BOARD
2-26. MECHANISM DECK (CDM74HFV ASSY)
– Bottom view –
2 screw
(BVTP 3 u8)
2 two screws
(BVTP 3 u8)
7 mechanism deck
(CDM74HFV assy)
6 WIRE HOLDER A board
2 two screws
(BVTP 3 u8)
4 pet cover (down)
1 pet cover (up)
5 screw
(BVTP 2.6 (3CR))
3
1 four screws
(BVTP 3 u8)
cover (fan) back panelfan cable VIDEO board
OK NG
2 VIDEO board
:LUHVHWWLQJ
