89
HCD-PZ1D
SECTION 7
ELECTRICAL PARTS LIST
AMP BOARD
**********
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
0 C403 1-104-694-91 MYLAR 0.1uF 5% 100V
0 C404 1-104-694-91 MYLAR 0.1uF 5% 100V
C409 1-127-811-11 ELECT (BLOCK) 3300uF 20% 50V
C410 1-127-811-11 ELECT (BLOCK) 3300uF 20% 50V
C413 1-136-497-81 FILM 0.1uF 5% 50V
C414 1-136-497-81 FILM 0.1uF 5% 50V
C415 1-114-915-91 FILM 0.01uF 5% 250V
C417 1-114-915-91 FILM 0.01uF 5% 250V
C418 1-114-915-91 FILM 0.01uF 5% 250V
C419 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C420 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C423 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C424 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C425 1-126-946-11 ELECT 6800uF 20% 25V
C426 1-126-946-11 ELECT 6800uF 20% 25V
C427 1-136-165-00 FILM 0.1uF 5% 50V
C428 1-136-165-00 FILM 0.1uF 5% 50V
C429 1-136-165-00 FILM 0.1uF 5% 50V
C430 1-136-165-00 FILM 0.1uF 5% 50V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C433 1-126-967-11 ELECT 47uF 20% 50V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C440 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C441 1-126-964-11 ELECT 10uF 20% 50V
C442 1-126-964-11 ELECT 10uF 20% 50V
C443 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C444 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C445 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C446 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C447 1-126-967-11 ELECT 47uF 20% 50V
C448 1-126-967-11 ELECT 47uF 20% 50V
C451 1-136-497-81 FILM 0.1uF 5% 50V
C452 1-136-497-81 FILM 0.1uF 5% 50V
C453 1-136-497-81 FILM 0.1uF 5% 50V
C454 1-136-497-81 FILM 0.1uF 5% 50V
C455 1-136-497-81 FILM 0.1uF 5% 50V
C456 1-136-497-81 FILM 0.1uF 5% 50V
0 C461 1-128-562-91 ELECT 47uF 20% 100V
0 C462 1-128-562-91 ELECT 47uF 20% 100V
C463 1-126-965-11 ELECT 22uF 20% 50V
C464 1-104-658-91 ELECT 100uF 20% 10V
C465 1-126-960-11 ELECT 1uF 20% 50V
C468 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
0 C475 1-127-814-11 ELECT (BLOCK) 3300uF 20% 80V
0 C476 1-127-814-11 ELECT (BLOCK) 3300uF 20% 80V
C477 1-126-964-11 ELECT 10uF 20% 50V
C478 1-126-960-11 ELECT 1uF 20% 50V
C480 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
* CN401 1-766-175-11 PIN, CONNECTOR (PC BOARD) 5P
* CN402 1-564-516-11 PLUG, CONNECTOR 13P
* CN403 1-573-087-11 PIN, CONNECTOR 13P
* CN405 1-573-087-11 PIN, CONNECTOR 13P
CN407 1-815-445-11 PIN, CONNECTOR (PWB) 4P
< DIODE >
D401 8-719-054-89 DIODE D15XB60
D402 6-502-994-01 DIODE D10XB60 F
D404 8-719-077-77 DIODE D3SB60F3
D406 6-501-817-01 DIODE MA2J1110GLS0
D407 6-500-334-01 DIODE MC2836-T112-1
D408 6-501-817-01 DIODE MA2J1110GLS0
D409 8-719-045-48 DIODE FML-G12S
D410 8-719-045-48 DIODE FML-G12S
D413 8-719-923-92 DIODE MTZJ-T-77-16B
D414 8-719-923-92 DIODE MTZJ-T-77-16B
D415 6-502-961-01 DIODE DA2J10100L
D416 6-501-817-01 DIODE MA2J1110GLS0
D417 6-502-961-01 DIODE DA2J10100L
D418 6-502-961-01 DIODE DA2J10100L
D419 6-502-972-01 DIODE DZ2J09100L
D420 8-719-077-77 DIODE D3SB60F3
D421 6-501-768-01 DIODE MAZ8120GMLS0
D422 6-501-817-01 DIODE MA2J1110GLS0
D423 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC401 6-717-193-01 IC STK416-130F-E
< TERMINAL BOARD >
JK401 1-780-756-1
1 TERMINAL BOARD (6P)
(FRONT SPEAKERS, SUBWOOFER)
JK403 1-694-091-11 TERMINAL BOARD (4P) (SATELLITE SPEAKERS)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
BR : Brazilian model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
MX : Mexican model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Ver. 1.1
To Next Page
