Side Flags

Chapter 9 Special Functions

DME wipe from a 4:3 image to a 16:9 image

Wipe action using slide (No. 1001)

DME wipe from a 4:3 image to another 4:3

image (when side flags are on for both

images)

Wipe action using squeeze (No. 1031)

Side flag area

16:9 image

4:3 image

(side flags on)

Auto crop on

Auto crop off

Side flag area

4:3 image

(side flags on)

Side flag area

4:3 image

(side flags on)

Side flag area

Auto crop off

Side flag area

Auto crop on

Side flag area
