About the Macro Attachment List Display
Appendix
Example of File Contents
About the Macro
Attachment List Display
The Button column in the macro attachment list displayed
in the status area of the Macro >Attachment menu (5421)
screen shows character strings which identify macro
attachment assigned buttons.
Each of these character strings is in fact a combination of
characters shown in the Button(1), Button(2), and
Button(3) columns in the following tables.
For example, if Block and Button(1) to Button(3) are:
Block: P/P XPT
Button(1): UTIL1 Bus
Button(2): V
Button(3): XPT2
Then, the display in the Button column is:
UTIL1 Bus V XPT2
which indicates “P/P row utility1 bus video signal, cross-
point button 2.”
M/E and PGM/PST Banks
The following table shows only the macro attachment
assignable buttons in the PGM/PST bank.
For the M/E1 bank, “P/P” changes to “M/E1” in the Block
Select and Block columns. In addition, “DSK” changes to
“KEY” in the Button(1) and Button(2) columns. The
contents of the Button(3) column do not change.
Block Select: P/P, Block: P/P XPT
KeyBusUtilityButton ME? ME1, PP Control blocks on the applicable bank
BANK? Bank1 to Bank5 Applicable bank
KeyBusUtilityButton
?
1 to 32 Applicable button
UtilityStatus? On,
Off,
Current (a)
Status of function assigned to button
(a): Operates according to currently assigned
function
ClipRecall Device? FrameMemory1Clip to
FrameMemory8Clip
Applicable clip
ClipType? Pair, Single File type of clip (pair/single)
Clip? Clip Name Name of clip (up to four characters)
DeviceRecord Device? 1 to 12 Applicable device
Line Content Description
1 PNL 0001PNL_0000.PMRMACROREG File header
2 #,Sample, Comment
3 Event?, Snapshot, Region?, ME1, Register?, 1,Attribute?, Off,Time?,
Current
Simultaneously recall snapshots from register
number 1 in the M/E-1 and PGM/PST regions.
4 Continue?, Snapshot, Region?, PP, Register?, 1,Attribute?, Off,Time?,
Current
5 Event?, MEXpt, ME?, ME1, MEBus?, A, Xpt?, 1, VideoKey?, Video Select button number 1 on the M/E-1 A bus.
Symbol Parameter name Arguments Description
Button (1) Button (2) Button (3)
A Bus
B Bus
DSK1 Bus
:
DSK4 Bus
(nothing)
Shift
XPT 1
:
XPT 128
M/E 1
P/P
DSK1 Src Bus
:
DSK4 Src Bus
V
K
V Shift
K Shift
UTIL1 Bus V
K
V Shift
K Shift
XPT 1
:
XPT 128
M/E 1
P/P
To Next Page
