229
Setting Button Assignments
Chapter 17 Control Panel Setup
a) For the safe title on/off commands (from ME1 PGM1 ST-ME1 PGM4 ST
to AUX1 ST-AUX24 ST), the name of the assigned output signal is
shown.
b) Pressing this button to turn it on enables key snapshot operations for all
control blocks.
Assigning a Function to 2nd Row
Cross-Point Buttons
You can assign functions to the 2nd row cross-point
buttons for the M/E-1 and PGM/PST banks.
1
Engineering Setup >Panel >Prefs/Utility >Xpt Module
Src/Reg Btn Assign menu (7324.2).
2
Select the button to be assigned.
3
In the <Action> group, select the function to be
assigned.
Menu Shortcut: Assigns a frequently used menu to be
recalled (menu shortcut).
Utility Command: Assigns a function enable/disable
or similar operation (utility command).
Macro Recall: Assigns a macro register recall.
Shotbox Recall: Assigns a shotbox register recall.
4
Depending on the selection in step 3, make the
following settings.
If Menu Shortcut is selected: With the 2nd row
cross-point buttons flashing, press one of the
cross-points buttons after displaying the menu for
which you want to create a shortcut to assign the
menu shortcut. To finish the assignment, press
[Menu Shortcut] again.
If Utility Command is selected: A list of commands
appears on the right of the status area, select the
command you want to assign.
SWR GPI1 Test Fire
|
SWR GPI8 Test Fire
Output test trigger from switcher GPI1
|
Output test trigger from switcher GPI8
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
Panel GPI1 Test Fire
|
Panel GPI8 Test Fire
Output test trigger from panel GPI1
|
Output test trigger from panel GPI8
Output (lights only at
the instant the button
is pressed)
When the output is
assigned
Macro Attachment Enbl Enable/disable macro attachment Enabled Disabled
Macro Only Set Macro only mode on/off On Off
Pre Macro Set macro attachment in pre macro
mode
Can be set only while
pressed (lit)
When the function is
assigned
Post Macro Set macro attachment in post macro
mode
Can be set only while
pressed (lit)
When the function is
assigned
Macro Take Macro execution During execution When the function is
assigned
Macro Cancel Cancel a macro Lit only at the instant
the button is pressed
When the function is
assigned
Macro Auto Ins Macro auto insert mode on/off On Off
Macro AT with Rate When registering an auto transition
macro event, on/off setting of mode to
save transition rate
On Off
Macro AT with A/B Bus When registering an auto transition
macro event for the transition control
block, on/off setting of mode to save A/
B Bus cross-point settings
On Off
Macro TL with Region When registering a timeline macro
event, on/off setting of mode to save
applicable region
On Off
System Manager Enbl Enable/disable operation from System
Manager
Enabled Disabled
Inhibit Set Inhibit cross-point button Can be set only while
pressed (lit)
When the function is
assigned
Inhibit All Clear Clear all cross-point button inhibit
settings
Can be set only while
pressed (lit)
When the function is
assigned
K-SS Store Enable/disable key snapshot saving
b)
Enabled Disabled
Command name
a)
Function Button status
Lit amber Off
To Next Page
