Sony MVS-3000 System User Manual

245
Signal Input Settings
Chapter 18 Switcher Setup
2 Adjust the following parameter.
To return the edge crop image to the center
Press [Cancel].
Setting the image position in letter box up-
conversion mode
1 In the <Letter Box Position> group of the Engineering
Setup >Switcher >Input >FC Adjust menu (7332.2),
press [Position], turning it on.
2 Adjust the following parameter.
To return the letterbox image to the center
Press [Cancel].
Making enhancer settings
1 In the Engineering Setup >Switcher >Input >FC
Adjust menu (7332.2), press [Enhancer], turning it on.
2 Set the following parameters.
Making detailed settings for down-
conversion
1 In the Engineering Setup >Switcher >Input >FC
Adjust menu (7332.2), select the input to which the
setting applies.
2 In the <Aspect> group, select one of the following.
Edge Crop: Crops the left and right sides of a 16:9
image to convert it to a 4:3 image.
Letter Box 13:9: Crops the left and right sides of a
16:9 image to make a 13:9 image and add black
bars at the top and bottom of the 13:9 image to
make a 4:3 image.
Letter Box 14:9: Crops the left and right sides of a
16:9 image to make a 14:9 image and add black
bars on the top and bottom of the 14:9 image to
make a 4:3 image.
Letter Box 16:9: Adds black bars on the top and
bottom of a 16:9 image to convert it to a 4:3 image.
Squeeze: Compresses a 16:9 image horizontally to
convert it to a 4:3 image.
(For details about the image transformations, see the
following figure.)
No. Parameter Adjustment
2 EC Position Image position
No. Parameter Adjustment
2 LB Position Image position
Parameter group [1/2]
No. Parameter Adjustment
2 Detail Gain Adjust the edge enhancement
sharpness
3 Limiter Adjust the maximum signal level
to be added to the original signal
4 Crisp Set the amplitude value for which
a low-amplitude signal is not
emphasized
5Level
Depend
Set the luminance range for edge
enhancement
Parameter group [2/2]
No. Parameter Adjustment
2 Frequency Set the center frequency for edge
enhancement
3 H/V Ratio Set the horizontal/vertical ratio for
edge enhancement
