13
No. Device
Description
A DC cabinet
That includes fuses and DC switches. Cooper
bars at the bottom of the DC cabinet are used for
DC-side cable connections.
B AC cabinet
That includes AC circuit breakers and RS485
communication terminals.
C Air outlets
-
3.2.2 Internal Devices of the Inverter
The inverter contains the DC cabinet, the module cabinet, the AC cabinet. The DC cabinet,
the AC cabinet are all equipped with wiring terminals and operation switches
DC Cabinet
figure 3-1 DC cabinet
System Manual 3 Product Description
