55
No.
Description
E
Language selection button. Click it to change languages among English,
Chinese and the like.
F Present date and time
G The success rate of the inverter internal communication
H The success rate of communication between the inverter and PC
Enter the following submenus from the default menu.
LCD screen contains lots of parameters pertinent to the inverter operation. All
parameters must be set by appointed personnel. Do not modify any parameters
without full understanding of the relevant action or without consulting Sungrow
Customer Support.
9.2.3 Backlight and Screensaver
If no operation has been performed on the screen for more than 5 minutes, the backlight will
go off. Tap the screen to activate the backlight so that the latest interface reappears.
9.3 Overview of LCD Menu and Icon
9.3.1 Overview of Submenu and Icon
There are three buttons on the lower left side of the touch panel: for the user to operate
“Start/Stop”
, “Home”, , “Function” . The user can perform related
operations via these buttons. The logical structures of these menus are shown below:
Main Menu
First sub-
menu
Second sub-menu Third sub-menu
Start/Stop
Start
- -
Stop
- -
Home
- - -
Function
Run-
information
Real-Time Data
-
Power curve
-
E-histogram
-
History-
information
His-event
-
His-fault
-
His-data
-
His-alarm
-
Start/Stop
Start
-
System Manual 9 LCD Menu Operation
