22
No.
Description
A
Top lifting rings, a total of 4, used only for fixing inverter during
transportation
Notice:
1. The hoisting ring is only for transportation, and it is strictly
prohibited for lifting the inverter.
2. When using ropes to fix the top lifting ring to the
transportation vehicle, it is strictly forbidden to scratch the
inverter cabinet with the rope.
B
There are 4 bottom lifting eyes, which can be used to fix the inverter
during transportation, or to hook the inverter base during lifting.
– When transporting by forklift, be sure to observe the markings and prompt
instructions on the bottom of the inverter.
• An additional traction vehicle may be required for uphill/downhill road transport.
• Anything, which may hinder the transport, like trees, cables (or the like), should be
removed.
• Transport the inverter on fine weather daysas far as reasonably possible.
• Warning signs or barriers must be posted near the transport areas to avoid accidental
injuries.
Additionally, the following requirements should be met when the inverter is placed on the
ground:
• Place the inverter carefully and gently. Do not pull or push the inverter on any surface.
• The place should be firm and flat with good drainage and no obstacles or outshoots. The
inverter should be supported by the four feet.
5.2 Hoisting the Inverter
5.2.1 Safety Precautions
• Observe the safety operating rules of the crane at all times.
• Standing within 5 to 10 meters away from the hoisting areas is strictly
prohibited! Anybody standing under the boom or inverter is strictly prohibited
in the whole hoisting process.
• The hoisting work must be stopped on violent weather days. For example, in
strong wind, heavy rain, or thick fog conditions.
Observe the following items:
• All safety requirements must be met.
5 Mechanical Installation System Manual
