39
6.5 AC Connection
6.5.1 Safety Notices
Incorrect AC connection may cause damages to the module.
Electrical shock hazards!
• Do not touch the live components.
• Disconnect the AC switches and ensure all terminals are voltage-free.
• The connections to the downstream devices must be carried out only after
receiving approval from the distribution utility as required by national and state
interconnection regulations.
Strictly follow all the instructions when connecting.
Strictly follow all device internal instructions when closing/opening the AC
switches.
Overview
Two versions of the inverter are provided on the AC side: AC connection area on the side,
AC connection area at the bottom. For the corresponding wiring schemes, please refer
to"6.5.3 AC Connection Area at the Bottom"and "6.5.2 AC Connection Area on the Side".
6.5.2 AC Connection Area on the Side
Preparation before Wiring
Use a screwdriver to remove the protctection cover to expose the copper bar area.
System Manual 6 Electrical Installation
