28
5.4 Removing the Sealing Tapes
Before delivery, the air inlet of the inverter and the heat exchanger are all pasted with
sealing tapes, shown as A and B respectively. Removing these sealing tapes before the
inverter is put into operation.
5.5 Clearance Requirement
The minimum reserved clearances around the inverters are shown in the following figure.
A B C D E
1,000 2,500 2,500 2,500 2,500
Unit:mm.
5 Mechanical Installation System Manual
