7-8 FUEL SYSTEM AND THROTTLE BODY
• Remove the fuel pump ring locknut by using the special tool.
[ 09941-51010: Ring locknut wrench
"
• Remove the fuel pump assembly.
• Disconnect the fuel level gauge lead wire coupler.
• Remove the fuel level gauge.
• Disconnect the ground wire.
• Remove the fuel pressure regulator.
Gasoline is highly flammable and explosive. Keep
heat, spark and flame away.

Suzuki AN650 2002 Specifications

General

Displacement	638 cc
Compression Ratio	11.2:1
Fuel System	Fuel Injection
Ignition	Electronic ignition (Transistorized)
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-15
Rear Tire	160/60-14
Bore x Stroke	75.5 mm x 71.3 mm
Front Brakes	Disc
Fuel Tank Capacity	15 liters
Seat Height	750 mm
Transmission	CVT
