10-32 ELECTRICAL SYSTEM
BRAKE LIGHT/ TAILLIGHT, TURN SIGNAL LIGHT AND LICENSE LIGHT
BULB REPLACEMENT
Front turn signal light
• Remove the cap
1 and screw
2.
• Insert the suitable screwdriver into the screw hole.
• Remove the front turn signal light as shown.
• Remove the socket
3.
• Remove the bulb
4.
• Install the turn signal light in the reverse order of removal.
If you touch the bulb with your bare hands, clean the bulb with a cloth moistened with
alcohol or soapy water to prevent premature bulb failure.
!

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki AN650 2002 and is the answer not in the manual?

Suzuki AN650 2002 Specifications

General IconGeneral
Displacement638 cc
Compression Ratio11.2:1
Fuel SystemFuel Injection
IgnitionElectronic ignition (Transistorized)
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionSwingarm type, coil spring, oil damped
Rear BrakesSingle hydraulic disc
Front Tire120/70-15
Rear Tire160/60-14
Bore x Stroke75.5 mm x 71.3 mm
Front BrakesDisc
Fuel Tank Capacity15 liters
Seat Height750 mm
TransmissionCVT
