11-20 SERVICING INFORMATION
THROTTLE BODY INSTALLATION/HOSE ROUTING
Fuel pump
Fixed with clamp
Fuel feed hose
10˚
Forward
Backward
Intake pipe side
Air cleaner side
IAC hose
Top mark
LH RH
VIEW OF TOP
Clamp
A
B
IAC hose
PAIR hose
Pass through the PCV (breather) hose above the throttle cables.
VIEW OF “B”
IAT sensor
AP sensor
PAIR control solenoid valve
A
downward.
A
downward.
A
backward.
PCV (breather) hose
PAIR hose
Throttle cables
B
top side.
B
top side.
B
top side.
IAC hoseIAC hose
A
top side.
A
top side.
VIEW OF “A”
Vacuum hose
Fuel feed hose
IAC hose
AP sensor
IAT sensor
18 N·m
(1.8 kgf-m, 13.0 lb-ft)
TP sensor
Vacuum hose
A
: The end of the clamp should face....
B
: The clamp screw head should face....

Suzuki AN650 2002 Specifications

General

Displacement	638 cc
Compression Ratio	11.2:1
Fuel System	Fuel Injection
Ignition	Electronic ignition (Transistorized)
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-15
Rear Tire	160/60-14
Bore x Stroke	75.5 mm x 71.3 mm
Front Brakes	Disc
Fuel Tank Capacity	15 liters
Seat Height	750 mm
Transmission	CVT
