7-18 FUEL SYSTEM AND THROTTLE BODY


• Remove the IAC hose connector.
• Remove the throttle cable bracket.
• Remove the synchronizing screws.
NOTE:
Before removing the synchronizing screw, determine the setting
by slowly turning it clockwise and count the number of turns
required to lightly seat the screw. This counted number is impor-
tant when reassembling synchronizing screw to original position.
Never remove the throttle valve.
Avoid removing the throttle lever stopper screw
A.

Suzuki AN650 2002 Specifications

General

Displacement	638 cc
Compression Ratio	11.2:1
Fuel System	Fuel Injection
Ignition	Electronic ignition (Transistorized)
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-15
Rear Tire	160/60-14
Bore x Stroke	75.5 mm x 71.3 mm
Front Brakes	Disc
Fuel Tank Capacity	15 liters
Seat Height	750 mm
Transmission	CVT
