CHASSIS 9-51
DUST SEAL
Inspect the wheel dust seal lip for wear or damage. If any dam-
ages are found, replace the dust seal with a new one.
• Remove the dust seal with the special tool.
[ 09913-50121: Oil seal remover

BEARING
Inspect the play of the wheel bearings by hand while they are in
the wheel. Rotate the inner race by hand to inspect for abnormal
noise and smooth rotation. Replace the bearing if there is any-
thing unusual.
• Remove the wheel bearings by using the special tool.
[ 09921-20240: Bearing remover set

Do not reuse the removed dust seal.
The removed bearings must be replaced with the new
ones.

Suzuki AN650 2002 Specifications

General

Displacement	638 cc
Compression Ratio	11.2:1
Fuel System	Fuel Injection
Ignition	Electronic ignition (Transistorized)
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Front Tire	120/70-15
Rear Tire	160/60-14
Bore x Stroke	75.5 mm x 71.3 mm
Front Brakes	Disc
Fuel Tank Capacity	15 liters
Seat Height	750 mm
Transmission	CVT
