12. BODY COVER SYM
12-4
FRONT COVER
Removal
Remove the 8 mounting screws of front
cover from the inner box A.
Remove the 2 mounting screws between the
front cover and the inner box .
Remove the 1 mounting bolt of front cover
from the frame.
Remove the headlight wire connector and
then remove the front cover.
Installation
Install according to the reverse procedure
of removal.
bolt×1
wire connecto
To Next Page
