SYM 6. CYLINDER HEAD/VALVE

6-1

MECHANISM DIAGRAM....................6-1

PRECAUTIONS IN OPERATION .......6-2

TROUBLE SHOOTING.......................6-3

CAMSHAFT REMOVAL .....................6-4

CYLINDER HEAD REMOVAL ............6-6

CYLINDER HEAD DISASSEMBLY ....6-7

CYLINDER HEAD INSPECTION..........6-8

VALVE SEAT INSPECTION AND SERVICE

6-10

CYLINDER HEAD REASSEMBLY .......6-12

CYLINDER HEAD INSTALLATION......6-13

CAMSHAFT INSTALLATION ...............6-13

VALVE CLEARANCE ADJUSTMENT..6-14

MECHANISM DIAGRAM

0.8~1.2 kgf-m

0.7~1.1 kgf-m

1.0~1.4 kgf-m

0.8~1.2 kgf-m

1.0~1.4 kgf-m
