Sym Orbit User Manual

SYM 2. MAINTENANCE INFORMATION
2-1
PRECAUTIONS IN OPERATION .......2-1
PERIODICAL MAINTENANCE
SCHEDULE ........................................2-2
LUBRICATION SYSTEM....................2-3
FUEL SYSTEM...................................2-4
AIR CLEANER....................................2-5
THROTTLE VALVE OPERATION ......2-5
VALVE CLEARANCE INSPECTION &
ADJUSTMENT....................................2-6
CARBURETOR IDLING SPEED
ADJUSTMENT ..................................2-7
IGNITION SYSTEM/SPARK PLUG ..2-8
CYLINDER COMPRESSION
PRESSURE........................................2-9
DRIVING SYSTEM............................. 2-9
STEERING SYSTEM .........................2-10
SUSPENSION SYSTEM .................... 2-10
FRONT DISK BRAKE SYSTEM .........2-11
DRUM BRAKE SYSTEM....................2-13
WHEEL/TIRE......................................2-14
BATTERY...........................................2-15
HEADLIGHT ADJUSTMENT.............. 2-15
NUTS、BOLTS TIGHTEN.................. 2-15
PRECAUTIONS IN OPERATION
Specification
Main 5200 c.c.
Fuel Tank Capacity
auxiliary 1500 c.c.
capacity 850 c.c.
Engine Oil
change 750 c.c.
capacity 110 c.c.
Transmission Gear oil
change 100 c.c.
Clearance of throttle valve 2~6 mm
Spark plug TORCH D7RC Gap: 0.6~0.7 mm
“F” Mark in idling speed Before TDC 13º / 2200 rpm
Full timing advanced Before TDC 26º / 8000 rpm
Idling speed 2100±100 rpm
Cylinder compression pressure 11.8±0.4:1 kg/cm²
Valve clearance: IN/EX 0.06±0.02 mm
Tire dimension front / rear 120/70-12 / 130/70-12
single Front: 2.00 kg/cm² rear: 2.00 kg/cm²
Tire pressure (cold)
Two persons Front: 2.00kg/cm² rear: 2.25 kg/cm²
Battery YTX7A-BS 12V6Ah (MF battery)
Play of drum brake lever 10~20 mm

Sym Orbit Specifications

General

Brand	Sym
Model	Orbit
Category	Scooter
Language	English
