SYM 16. ELECTRICAL EQUIPMENT
16-1
MECHANISM DIAGRAM ....................16-1
PRECAUTIONS IN OPERATION .......16-2
SPECIFICATION ................................16-3
TROUBLE DIAGNOSIS......................16-4
CHARGING SYSTEM.........................16-5
IGNITION SYSTEM ............................16-11
STARTING SYSTEM..........................16-14
METER ...............................................16-15
LIGHTS/BULBS ..................................16-17
MAIN SWITCH/HORN ........................16-19
FUEL UNIT .........................................16-22
MECHANISM DIAGRAM
Spark plug
Alternator
Fuel unit
Ignition coil
Battery/ fuse box
/C.D.I
Main switch
REG.REC/Horn/
/Resistor
Starter magnetic
switch
Starting/headlight
switch
High & low beam/Passing/turn
signal light/Horn
Auto by-star
Front/Rear stop
switch
Winker relay
Engine start
control switch
To Next Page
