Sym Orbit User Manual

SYM 1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-9
SPECIFICATIONS
MAKER SANYANG MODEL AAA(AV05W-6)
Overall Length 1906mm Front Telescopic fork
Overall Width 694mm
Suspen
sion
System
Rear Single swing arm
Overall Height 1138 mm Front 120/70-12(56J)
DIMENSION
Wheel Base 1327mm
Tire
Specifi
cations
Rear 130/70-12(56J)
Front 40kg
Rear 59kg
Front DISK (ø 190 mm)
Curb Weight
Total 99kg
Brake
System
Rear DRUM (ø 110 mm)
Passengers/
Weight
Two men/150 kg Max. Speed 45km/h
Front 84kg
Performa
nce
Climb Ability 20° Below
Rear 125kg Primary Reduction BELT
WEIGHT
Total Weight
Total 209kg
Secondary
Reduction
GEAR
Type 4-STROKE ENGINE Clutch Centrifugal, dry type
Installation and
arrangement
Vertical, below center,
incline 80°
Deceleration
equipment
Transmission C.V.T.
Fuel Used Petrol Speedometer 0 ~ 80 km/hr
Cycle/Cooling
4-stroke/forced air
cooled
Horn 95~115dB(A)
Bore φ39.0 mm Muffler Expansion & Pulse Type
Stroke 41.5 mm
Exhaust Pipe Position
and Direction
Right side, and
Backward
Cylinder
Number/Arran
gement
Single Cylinder/
horizontal
Lubrication System
forced-circulation&
splashing
Displacement 49.5 cc CO <12.0 g/km
Compression
Ratio
11.8:1
Max. HP 2.35KW/8500 rpm
Exhaust
Emission
HC <1.0 g/km
Max. Torque 2.91N.m /6500 rpm Air Filtration Paper filter
Ignition C.D.I. Noise Emission < 70dB
ENGINE
Starting System Electrical & foot type
Engine Weight(dry
weight)
23kg

Sym Orbit Specifications

General

Brand	Sym
Model	Orbit
Category	Scooter
Language	English
