SYM 15. REAR WHEEL/REAR SHOCK ABSORBER
15-1
MECHANISM DIAGRAM.................... 15-1
PRECAUTIONS IN OPERATION....... 15-2
TROUBLE DIAGNOSIS .....................15-2
EXHAUST MUFFLER.........................15-3
REAR WHEEL....................................15-3
REAR SHOCK ABSORBER............... 15-4
MECHANISM DIAGRAM
0.8~1.2kgf-m
3.0~3.6kgf-m
11.0~13.0kgf-m
1.0~1.4kgf-m
2.4~3.0kgf-m
3.5~4.5kgf-m
