12. BODY COVER SYM
12-6
FRONT INNER BOX A
Removal
Remove the 8 mounting screws of front
cover from the inner box A.
Remove the screw on the front inner box.
Remove the front cover.
Remove the screw on the main switch.
Remove the main switch cover.
Remove the 4 screws between the inner box
A and the inner box B.
1 screw
8 screws
1 bolt
4 screws
To Next Page
