TM8100/TM8200 Service Manual Disassembly and Reassembly 129

5 Disassembly and Reassembly

This section describes how to:

■ remove and mount the control head

■ disassemble and reassemble the radio body

■ disassemble and reassemble the control heads.

General Important Before disassembling the radio, disconnect the radio from

any test equipment or power supply.

Disassemble only as much as necessary to replace the defective parts.

Inspect all disassembled parts for damage and replace them, if necessary.

Observe the torque settings indicated in the relevant figures.

For information on spare parts, refer to “Spare Parts” on page 437.
