TM8100/TM8200 Service Manual TMAA10-04 Remote PTT Kit and TMAA10-05 Hands-Free Kit 561
© Tait Electronics Limited June 2006
32 TMAA10-04 Remote PTT Kit and
TMAA10-05 Hands-Free Kit
The TMAA10-04 remote PTT kit and the TMAA10-05
hands-free kit plug into the radio’s auxiliary connector.
Both kits use the remote electret microphone to replace
communication through the usual rugged microphone.
The rugged microphone can still provide hookswitch
operation, if this is required.
The TMAA10-04 kit uses a conveniently mounted remote
PTT key for PTT operation. When the remote PTT is
activated, the remote microphone is used for communication.
There are three mounting options for the remote microphone
and an extension lead is provided for the remote PTT in the
TMAA10-04 kit.
32.1 VOX Operation (TMAA10-05 Hands-Free Kit)
Your radio may able to detect the sound of your voice, so that you can make
calls without using the PTT key. Voice-operated transmit (VOX) is turned
on and off either by using a function key programmed for VOX or by
using the radio’s Main menu.
Changing to VOX
Using a Function
Key
The function key programmed for VOX toggles VOX between on and off.
When VOX is turned on, it remains on until the function key is pressed again.
While VOX is on, the VOX indication may be
programmed to appear below the channel infor-
mation on your display.
Changing to VOX by
using the Main
Menu
1. Select Menu>Radio Settings>
Function Settings>VOX.
Important These kits do not meet the IP54 pro-
tection standard. Care must be taken
when a radio with a TMAA10-04 or
TMAA10-05 kit installed is being
operated in an environment where
there is water, dust or other
environmental hazards.
auxiliary
connector plug
extension lead for
remote PTT
remote microphone
remote PTT (TMAA10-04)
remote microphone
mounting options
