How to enable / disable cursor in the oscilloscope

Use this procedure to enable / disable cursor manually.

NOTE. To disable or enable the Cursor function requires a password. The default

factory password is 000000.

NOTE. An instructor in a TekSmartlab

™

-equipped education lab can enable or

disable Cursor from the TekSmartLab application, for all connected

oscilloscopes.

1. Push Utility.

2. Push -More- Page 1/2 side-menu button.

3. Push Feature Enable side-menu button.

4. Use the Multipurpose knob to select and click Cursor Enable. The

oscilloscope opens the Feature Enable password entry screen.

Analyzing a waveform

TBS2000B Series Oscilloscopes User Manual 107
