5. Turn the Multipurpose knob to select Run Self Test, then click the
Multipurpose knob to start testing using the default settings. the self test
takes a few seconds to run.
6. Use the other Self Test menu items to refine how to run the self test; you can
run the tests a specified number of times (Loop Times), run tests forever
(Loop Forever), run tests until a test fails and stop testing (Loop Until Fail),
or run a test on a failed tests (Loop On Failure).
NOTE. The oscilloscope resets to the factory default settings after running the self
tests.
Courseware on-instrument education and training
Run guided lab exercises right on your oscilloscope. Read overview theory and
procedures, and capture your lab results right there as well.
Create new course materials on a PC with separate PC-based Courseware
software, which you can download from www.tek.com/software. After you create
the course materials, you can distribute them to supported oscilloscopes using a
USB drive or from the TekSmartLab software server.
NOTE. TekSmartLab uses wireless connectivity to connect multiple oscilloscopes
and other test bench instruments to a central server and software interface.
Using The TBS2000B series oscilloscope with TekSmartLab requires either a Wi-
Fi Transceiver USB dongle (Option TEKUSBWIFI) or a communication box to
connect to the TekSmartLab server. See the Scope Intro topic on TekSmartLab
for more information (Help ►Scope Intro ►TekSmartLab).
You can also go to the Courseware Web page at www.tek.com/courseware to
download courseware files that others have created and uploaded to share.
NOTE. Courseware files are compressed using .zip format. Unzip the Courseware
file and copy the uncompressed files to a USB drive.
Appendices
168 TBS2000B Series Oscilloscopes User Manual
