Greensmaster 3150 GroomerPage 8 -- 1 7
Disassembly (Fig. 16)
1. Remove flange nut (item 2) that secures lift a rm to
HOC groomer arm. Remove lock nut (item 16) and
springwasher(item17)thatsecureliftarmtosideplate.
Loosen lock screw (item 6) completely.
2. Remove lift arm from cutting unit.
3. Disassemble lift arm using Figure 16 as a guide.
NOTE: Right and left side HOC groomer arms (item 1)
andliftarmassemblies(item8)aredifferent;othercom-
ponentsshown in Figure16 are thesame on bothsides
of cutting unit.
NOTE: Groovedpin(item3)isusedtoretainlockscrew
(item 6) to lift arm assembly.
Assembly (Fig. 16)
1. Assemble lift arm using Figure 16 as a guide.
2. Apply antiseize lubricant to threads of groomer lift
rod (item 5) and lift arm assembly stud (item 8).
3. Installliftarmontocuttingunit.Securewithflangenut
(item 2) and lock nut (item 16) with spring washer (item
17).
4. Secure groomer in raised or lowered position with
lock screw (item 6).
5. Check and adjust grooming reel height and mower
height--of--cut settings.
