Toro Greensmaster
3150 Service Manual

Greensmaster 3150Groomer Page 8 -- 16
Lift Arm Assembly
Figure 16
1. HOC groomer arm (LH shown)
2. Flange nut
3. Grooved pin
4. E--ring
5. Groomer lift rod
6. Lock screw
7. Bushing
8. Lift arm assembly (LH shown)
9. Detent spring
10. Spring washer
11. Cap screw
12. Bushing
13. Wave washer
14. Groomer adjuster
15. Side plate (LH shown)
16. Lock nut
17. Spring washer
18. Bushing
13
3
5
14
2
6
4
7
12
9
10
8
11
7
1
Antiseize
Lubricant
Antiseize
Lubricant
Antiseize
Lubricant
17
16
18
15
