ENGINE
4-109TX525 Service Manual Rev. 000
49. Torquethestartermountingboltsto17.4-20.3ft-
lbs.(23.5-27.5Nm)(Fig.0488).
Fig 0488 PICT-5568
50. Positionthestarterbafeplate(Fig.0489).
Fig 0489 PICT-5501a
52. Torquethe2boltssecuringthestarterbafeplateto
theengineto17.4-20.3ft-lbs.(23.5-27.5Nm)(Fig.
0491).
Fig 0491 PICT-5569a
51. Usinga13mmsocket,install2boltssecuringthe
starterbafeplatetotheengine(Fig.0490).
Fig 0490 PICT-5500a
