ENGINE
4-40 Rev. 000 TX525 Service Manual
6. Usinga7/16”socket,install4boltsandlockwashers
securingthecoolingfantothefanmountspacer
(Fig.0221).
Fig 0221 PICT-5112a
7. Torquethe4boltsto100+10in-lbs.(11.3+1.1Nm)
(Fig.0222).
Fig 0222 PICT-5118a
8. Installtheradiatorandoilcoolerassembly.Referto
“Radiator&OilCoolerAssemblyInstallationonpage
4-15.
Flywheel Replacement
Flywheel Removal
1. Removethetandempumpassemblyfromthepump
mount.Referto“HydraulicTandemPumpRemoval”
onpage6-30.
2. Usinga13mmsocket,removethe4boltssecuring
thepumpmounttotheenginehousing(Fig.0223).
Fig 0223 PICT-4863
3. Removethepumpmount(Fig.0224).
Fig 0224 PICT-4861
