MAINTENANCE
3-25TX525 Service Manual Rev. 000
Fuse Block
Toaccessthefuses,youmustremovetheheatshield.
1. Stoptheengineandremovethekey.
2. Raisethehood.
3. Pullthehairpincotterfromthebottomendofthe
hoodproprodandslidetheproprodoutofthe
retainingbracketsandtheproprodtab.
4. Removethe4screwssecuringtheheatshieldand
thenpulltheshieldoutanduptoremoveit.
5. Checkthefuses.Replaceasnecessary(Fig.0069).
Note: Fuses can be removed to check continuity.
The test meter should read less than 1 ohm.
Fig 0069 PICT-8753
A. 30amp=Maincircuit
B. Empty
C. 10amp=Controlpanel/Relay
D. Openpositionforoptionalaccessories
AB
CD
6. Installtheheatshieldusingthe4screwsremoved
previously.
7. Installtheproprodintotheretainingbracketsand
proprodtabandsecureitwiththehairpincotter.
8. Closethehood.
Hydrostatic Pump Belt
Every25hoursinspectthedrivebeltforwearor
damage.
Replacethebeltifyoundanysignsofwear,cracks,or
damageoryearly,whichevercomesrst(Fig.0070).
Fig 0070 PICT-8756
