ENGINE
4-158 Rev. 000 TX525 Service Manual
22. Removethewasherfromtherotorshaft(Fig.0679).
Fig 0679 PICT-8208
23. UsingaPhillipsscrewdriver,removethe4screws
securingtheretainerplatetotheinsideofthedrive
endframe(Fig.0680).
Fig 0680 PICT-8192
24. Removetheretainerplatefromthedriveendframe
(Fig.0681).
26. Inspectthebearings,rotorshaftandbrushes.Re-
placeifwornordamaged.
27. Testthestator,rotor,slipring,brushwear,andrec-
tier.Referto“AlternatorTesting”onpage4-159.
Fig 0681 PICT-8194
25. Pressthebearingoutofthedriveendframe(Fig.
0682).
Fig 0682 PICT-8197a
