ENGINE
4-13TX525 Service Manual Rev. 000
2. Slidetheradiatorbracketontotheradiatorsothat
themountingholesintheangeslineup(Fig.0123).
4. Positiontheoilcoolerontotheradiatorbysliding
themountingangeontothe2boltssothatthe
mountingangeislocatedbetweentheradiatorand
theatwashers(Fig.0125).
Fig 0123 PICT-5098a
Fig 0125 PICT-5100
5. Looselyinstall2bolts,lockwashersandatwashers
throughthetopmountingangeoftheoilcoolerand
intotheradiator(Fig.0126).
3. Thread2bolts,lockwashersandwashersintothe
holeslocatedonthebottommountingange(Fig.
0124).
Fig 0126 PICT-5101
Fig 0124 PICT-5099
