Toshiba TOSVERT VF-MB1 User Manual

E6581697
F-98
6
6.27 Analog input terminal function selection
f214 : VIB input point 1 rate
f215 : VIB input point 2 rate
f663 : Analog input terminal function selection (VIB)
 Function
Parameter inputting is normally set from operation panel. However some parameters can be continuously
set from external analog input by using this function.
[Parameter setting]
Title Function Adjustment range Default setting
f214
VIB input point 1 rate -250-+250 (%) 0
f215
VIB input point 2 rate -250-+250 (%) 100
f663
Analog input terminal function
selection
(VIB)
0: Frequency command
1: Acceleration/deceleration time
2: Upper limit frequency
3, 4: -
5: Torque boost value
6: Stall prevention level
7: Motor electronic-thermal protection level
8 to 10: -
11: Base frequency
0
+ VIB terminal can be assigned analog input terminal function. The range of analog input voltage is 0% to +100%.
From -100% to 0% cannot be used.
+ The parameter that is selected by f663 can be adjusted range as following table.
Setting of f663 Object parameter VIB : 0% input VIB : 100% input
0: Frequency
command
- - -
1: Acceleration/
deceleration time
acc, dec, f500,
f501, f510, f511
Parameter setting value x
f214
Parameter setting value x
f215
2: Upper limit
frequency
ul
Parameter setting value x
f214
Parameter setting value x
f215
5: Torque boost
value
vb, f172
Parameter setting value x
f214
Parameter setting value x
f215
6: Stall prevention
level
f185, f601
Parameter setting value x
f214
Parameter setting value x
f215
7: Motor electronic-
thermal protection
level
thr, f173
Parameter setting value x
f214
Parameter setting value x
f215
11: Base frequency
vlv, f171
Parameter setting value x
f214
Parameter setting value x
f215
Note: Adjustments are made by the inverter itself, so no changes are made to parameter settings
