Toshiba TOSVERT VF-MB1 User Manual

E6581697
K-7
11
 Basic parameter 2
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0170 Base frequency 2 Hz 0.1/0.01 20.0-500.0 *1

0171 Base frequency
voltage 2
V 1/0.1 50-330 (240V class)
50-660 (500V class)
*1

0172 Torque boost
value 2
% 0.1/0.1 0.0-30.0 *2
6.4.1

0173 Motor electronic-
thermal protection
level 2
%
(A)
1/1 10-100 100 3.5
6.4.1
6.24.1

0185 Stall prevention
level 2
%
(A)
1/1 10-199,
200 (disabled)
150 6.4.1
6.24.2

0190 V/f 5-point setting
VF1 frequency
Hz 0.1/0.01
0.0-fh
0.0 5.12
6.5

0191 V/f 5-point setting
VF1 voltage
% 0.1/0.01
0.0-125.0
0.0

0192 V/f 5-point setting
VF2 frequency
Hz 0.1/0.01
0.0-fh
0.0

0193 V/f 5-point setting
VF2 voltage
% 0.1/0.01
0.0-125.0
0.0

0194 V/f 5-point setting
VF3 frequency
Hz 0.1/0.01
0.0-fh
0.0

0195 V/f 5-point setting
VF3 voltage
% 0.1/0.01
0.0-125.0
0.0

0196 V/f 5-point setting
VF4 frequency
Hz 0.1/0.01
0.0-fh
0.0

0197 V/f 5-point setting
VF4 voltage
% 0.1/0.01
0.0-125.0
0.0

0198 V/f 5-point setting
VF5 frequency
Hz 0.1/0.01
0.0-fh
0.0

0199 V/f 5-point setting
VF5 voltage
% 0.1/0.01
0.0-125.0
0.0
 Frequency parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0:  (Switchable to  by
terminal input)

0200 Frequency priority
selection
- -
1:  (Switchable to  at
1.0Hz or less of designated
frequency)
0 6.6.1
7.3

0201 VIA input point 1
setting
% 1/1 0-100 0

0202 VIA input point 1
frequency
Hz 0.1/0.01 0.0-500.0 0.0

0203 VIA input point 2
setting
% 1/1 0-100 100

0204 VIA input point 2
frequency
Hz 0.1/0.01 0.0-500.0 *1
6.6.2
7.3

0205 VIA input point 1
rate
% 1/0.01 0-250 0

0206 VIA input point 2
rate
% 1/0.01 0-250 100
6.26

0207 Frequency setting
mode selection 2
- - 0-11 (Same as ) 1 6.3.4
6.6.1
7.3
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*2: Default setting values vary depending on the capacity. Refer to section 11.4.
