3.2 Simplified Operation of the VF-MB1
The procedures for setting operation frequency and the methods of operation can be selected from the following.
Run / Stop
:
(1) Run and stop using the panel keypad
(2) Run and stop using external signals to terminal
board
Setting the frequency
:
(1) Setting using setting dial
(2) Setting using external signals to terminal board
(0-10Vdc, 4-20mAdc)
Use the basic parameters  (command mode selection) 
and (frequency setting mode selection) for selection.
[Parameter setting]
Title Function Adjustment range Default setting

Command mode selection
0: Terminal board
1: Panel keypad (including extension
panel)
2: RS485 communication
3: CANopen communication
4: Communication option
1

Frequency setting mode
selection
0: Setting dial 1(save even if power is off)
1: Terminal board VIA
2: Terminal board VIB
3: Setting dial 2(press in center to save)
4: RS485 communication
5: UP/DOWN from external logic input
6: CANopen communication
7: Communication option
8: Terminal board VIC
9, 10: -
11: Pulse train input
0
☆ fmod=0 (setting dial 1) is the mode that after the frequency is set by the setting dial, the frequency is saved
even if the power is turned off.
☆ Refer to section 5.6 for details about = to  and 11.
