6.28 Adjustment parameters
6.28.1 Pulse train output for meters
f669 : Logic output/pulse train output selection (OUT)
f676 : Pulse train output function selection (OUT)
f677 : Maximum numbers of pulse train output
f678 : Pulse train output filter
 Function
Pulse trains can be sent out through the OUT output terminals.
To do so, it is necessary to select a pulse output mode and specify the number of pulses.
Ex.: When operations frequencies (0 to 60Hz) are put out by means of 0 to 600 pulses
fh=60.0, f669=1, f676=0, f677=0.60
[Parameter setting]
Title Function Adjustment range
Reference
of maximum
value of
f677
Default
setting
f669
Logic output/pulse train
output selection (OUT)
0: Logic output
1: Pulse train output
– 0
f676
Pulse train output function
selection (OUT)
0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5: Input power
6: Output power
7: Torque
8: -
9: Motor cumulative load factor
10: Inverter cumulative load factor
11: PBR (Braking resistor) cumulative
load factor
12:Stator frequency
13:VIA input value
14:VIB input value
15:Fixed output 1
(output current 100% equivalent)
16:Fixed output 2
(output current 50% equivalent)
17:Fixed output 3
(Other than the output current)
18:Communication data
19: -
20: VIC input value
21, 22: -
23: PID feedback value
fh
185%
fh
150%
150%
185%
185%
250%
-
100%
100%
100%
fh
10 V
10 V
185%
185%
100%
100.0%
-
20mA
-
100%
0
