Toshiba TOSVERT VF-MB1 User Manual

E6581697
L-4
12
12.2 Outside dimensions and mass
 Outside dimensions and mass
Dimensions (mm)
Voltage class
Applicable motor
(kW)
Inverter type
W H D W1 H1 H2
Drawing
Approx. weight
(kg)
0.2 VFMB1S-2002PL
0.4 VFMB1S-2004PL
1.7
0.75 VFMB1S-2007PL
45 29 A
1.8
1.5 VFMB1S-2015PL 2.1
1-phase 240V
2.2 VFMB1S-2022PL
60
270 232
42
258 47
B
2.2
0.4 VFMB1-4004PL 1.8
0.75 VFMB1-4007PL
1.5 VFMB1-4015PL
45 29 A
1.9
2.2 VFMB1-4022PL 2.2
4.0 VFMB1-4037PL
60
270
42
258 47
B
2.4
5.5 VFMB1-4055PL
7.5 VFMB1-4075PL
150 220 130 210 12 C 4.3
11 VFMB1-4110PL 6.8
3-phase 500V
15 VFMB1-4150PL
180 310
232
160 295 20 D
6.9
Note. H dimension in Fig. C is not included in the protuberance for operation panel.
 Outline drawing
Fig.A
123
14
7258
248
H1(Mounting dimension)
D
7
5.45
R2.75
R2.75
5.45
φ5.5
φ10
HH2
W
W1(Mounting dimension)
8
φ5.5
φ5
φ10
